JETRIX LXi7 UV flatbed printer

Shipping time :

3 months

Request for quotation

High quality industrialUV flatbed printer. Max. size: 2500x3050mm

JETRIX LXi7 flatbed UV printer

Excellent performance and price/value ratio! With its huge table size, you can directly on the surface of print entire boards. This printer combines high quality printing with amazing productivity, with a print speed of up to 78 m²/hour. The LXi7 flatbed UV printer has the same technical parameters as the LXi6, except for the size of the printable board, which in the case of the LXi7 is a maximum of 2500×3050 mm.

Industrial printheads

The JETRIX LXi7 uses Konica Minolta KM1024i print heads, which provide excellent resolution of 1080 dpi and outstanding speed. The print quality is further improved by the Nozzle Recovery and Variable Dot technologies, which ensure streak-free, continuous stable quality.

Industrial speed

This printer can even meet the needs of the largest corporate customers with a speed of 78 m²/hour and continuous stable photo quality. In fine art top quality printing, 23 m²/hour can be achieved, which is outstanding in its category.

Board handling

Zonal vacuum control and stop pins make it easier to continuously change the raw material and fix it under vacuum. Anti-crash system protects the printheads and infra-red guided sensor provides the safety of the operator. You don't have to give up printing on thicker boards or objects either, because the LXi6 can print on up to 100 mm thickness.

INKTEC complete system: Printer–Ink–Print media!

With the JETRIX printer, you buy a complete industrial system capable of striking. INKTEC develops printers, printing supplies and print media in-house. You can see and test the outstanding scratch resistance and high color gamut of LX-LED paints in person as well in our showroom. The new generation paint and LED UV technology results in wide media compatibility on both flexible and rigid materials!

LED curing

The JETRIX UV flatbed printer includes the latest LED UV lamp technology. It ensures stable, eco-friendly industrial printing with extremely low energy consumption, no warm-up time and an extended lifetime of 20,000 hours.

Expansive variety of applications

A JETRIX LXi7 UV flatbed printer could be used in various areas such as outdoor advertisements, home decor, office decoration, packaging design and many more. It could be used to print on a variety of materials (acril, dibond, wood, coroplast, etc.) and – after adequate surface treatment with precoat liquid – you could print with it on even more materials, such as glass and plastic. What's more, you can even achieve 3D effect with multi-layer printing!

Data

Type:

UV flatbed printer

Brand:

Jetrix

Video

Specifications

Model: Jetrix LXi7
Type: Flatbed UV LED Printer
Printing speed: Fine art: 23 m²/h, Quality: 30 m²/h, Production: 44 m²/h, High speed: 78 m²/h
Printhead: Konica Minolta KM1024i
Ink curing: UV LED lamps
Max. print resolution: 1080×720 dpi
Print mode: CMYK+LC+LM (6 channel) / CMYK+LC+LM+W (7 channel) / CMYK+LC+LM+W+Varnish/Primer (8 channel)
Max. printable height: 100 mm
Max. printable size: 2500×3060 mm
Printable materials: acryl, pvc, petg, pc, glass, wood, aluminium, mdf, steel, etc.
Ink: Inktec LX-LED
Ink types: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White, Varnish, Primer
Table: automated zonal vacuum control
RIP recomendation: Caldera, Onyx
Sizes: 5090 mm (width) × 3800 mm (length) × 1620 mm (height)
Weight: 2500 kg
