JETRIX LXi8 UV flatbed printer

Shipping time :

3 months

Request for quotation

High quality industrialUV flatbed printer. Max. size: 3200x2030mm

JETRIX LXi8 flatbed UV printer

JETRIX LXi8 is INKTEC's high-end industrial UV printer, which can easily cover the printing needs of large companies! The GUI (Graphical User Interface) provides simplicity and transparency, with extremely simple printer management. In addition to handling, the main virtue of the LXi8 is productivity! Automatic zone vacuum table and impact pins, automatic head cleaning, the huge table surface, industrial Konica Minolta print heads and a printing speed of 206 m²/hour cover industrial printing needs.

Industrial printheads

The JETRIX LXi8 uses Konica Minolta KM1024i printheads, which provide excellent 1080dpi resolution and outstanding speed. The print quality is further improved by the Nozzle Recovery and Variable Dot technologies, which ensure streak-free, continuous, stable quality.

Industrial speed

The maximum speed of the LXi8 is 206 m²/hour, which is excellent for photo-quality outdoor media needs, but even at the maximum fine art top quality, 31 m²/hour can be achieved. This print performance is outstanding in this price range!

Board handling

Zonal vacuum control and stop pins make it easier to continuously change the raw material and fix it under vacuum. Anti-crash system protects the printheads and infra-red guided sensor provides the safety of the operator. You don't have to give up printing on thicker boards or objects either, because the LXi6 can print on up to 100 mm thickness.

INKTEC complete system: Printer–Ink–Print media!

With the JETRIX printer, you buy a complete industrial system capable of striking. INKTEC develops printers, printing supplies and print media in-house. You can see and test the outstanding scratch resistance and high color gamut of LX-LED paints in person as well in our showroom. The new generation paint and LED UV technology results in wide media compatibility on both flexible and rigid materials!

LED curing

The JETRIX UV flatbed printer includes the latest LED UV lamp technology. It ensures stable, eco-friendly industrial printing with extremely low energy consumption, no warm-up time and an extended lifetime of 20,000 hours.

Expansive variety of applications

A JETRIX LXi8 UV flatbed printer could be used in various areas such as outdoor advertisements, home decor, office decoration, packaging design and many more. It could be used to print on a variety of materials (acril, dibond, wood, coroplast, etc.) and – after adequate surface treatment with precoat liquid – you could print with it on even more materials, such as glass and plastic. What's more, you can even achieve 3D effect with multi-layer printing!

Data

Type:

UV flatbed printer

Brand:

Jetrix

Video

Specifications

Model: Jetrix LXi8
Type: Flatbed UV LED Printer
Printing speed: Fine art: 31 m²/h, Quality I: 48 m²/h, Quality II: 66 m²/h, Production: 98 m²/h, High speed: 206 m²/h
Printhead: Konica Minolta KM1024i
Ink curing: UV LED lamps
Max. print resolution: 1080×720 dpi
Print mode: CMYK+LC+LM (6 channel) / CMYK+LC+LM+W (7 channel) / CMYK+LC+LM+W+Varnish/Primer (8 channel)
Max. printable height: 100 mm
Max. printable size: 3200×2030 mm
Printable materials: acryl, pvc, petg, pc, glass, wood, aluminium, mdf, steel, etc.
Ink: Inktec LX-LED
Ink types: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White, Varnish, Primer
Table: automated zonal vacuum control
RIP recomendation: Caldera, Onyx
Sizes: 5690 mm (width) × 2775 mm (length) × 1619 mm (height)
Weight: 1750 kg
