JETRIX LXiR320 roll-to-roll UV printer

Shipping time :

3 months

Request for quotation

High quality industrial roll-to-roll UV printer. Width: 3200 mm

JETRIX LXiR320 roll UV printer

The JETRIX LXiR320 provides industrial productivity for the needs of large companies, combined with high print quality. With industrial Konica Minolta printheads, advanced functions and a print speed of up to 120 m²/hour, the LXiR320 is the first choice for high-volume outdoor advertising production.

Industrial print heads

The JETRIX LXiR320 roll UV printer uses Konica Minolta KM1024i print heads, which provide excellent quality and productivity with a print resolution of 720×1440 dpi and a speed of up to 92 m²/hour. The print heads are protected from damage by an anti-crash system.

Multi-roll printing

You could further increase your productivity when printing on smaller media with Multi-roll printing. Jetrix LXiR190 could handle up to 3 rolls whether it is paper, vinyl or polyester. In addition, its robust media capability also enables single rolls of media to be used up to 80 kg and 1880 mm width with front and rear double rollers ensuring consistently accurate feeding.

INKTEC complete system: Printer–Ink–Print media!

With the JETRIX printer, you buy a complete industrial system capable of striking. INKTEC develops printers, printing supplies and print media in-house. You can see and test the outstanding scratch resistance and high color gamut of LX-LED paints in person as well in our showroom. The new generation paint and LED UV technology results in wide media compatibility on both flexible and rigid materials!

LED curing

The JETRIX roll-to-roll UV printer includes the latest LED UV lamp technology. It ensures stable, eco-friendly industrial printing with extremely low energy consumption, no warm-up time and an extended lifetime of 10,000 hours.

Expansive variety of applications

A JETRIX LXiR320 roll-to-roll UV printer could be used in various areas such as outdoor advertisements, home decor, office decoration, the fashion industry and many more. It could be used to print on a variety of roll materials (different kinds of paper, vinyl and textiles such as polyester etc.).

Data

Roll width:

160 cm

Type:

roll-to-roll UV printer

Brand:

Jetrix

Video

Specifications

Model: Jetrix LXiR320
Type: Roll-to-Roll UV LED Printer
Printing speed: 8 pass: 36 m²/h, 6 pass: 46 m²/h, 4 pass: 68 m²/h, 2 pass: 92 m²/h
Printhead: Konica Minolta KM1024i
Ink curing: UV LED lamps
Max. print resolution: 720×1440 dpi
Print mode: CMYK+LC+LM+W
Max. printable width: 3200 mm
Printable materials: tarpaulin, vinyl, banner, etc.
Ink: Inktec LX-LED
Ink types: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, White
RIP recomendation: Caldera, GMG, Photo Print Server
Sizes: 5600 mm (width) × 1600 mm (length) × 1700 mm (height)
Weight: 2150 kg
